Frigidaire 316460504 Wiring Harness (Assembly) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316460504 replaces AP4298949, 1259624, AH1991723, EA1991723, PS1991723.

Description

This wiring harness assembly routes power and signals between the appliance's controls and key components, restoring electrical connections for reliable operation. It replaces a damaged or burnt harness to help resolve electrical faults and intermittent function. What it does:

• Transfers power and control signals between the control board and components such as motors, sensors, and switches
• Restores proper electrical connections to eliminate intermittent operation or component failures caused by damaged wiring
• Prevents short circuits and arcing when replacing frayed, burned, or corroded wires
• Matches OEM routing and connector types to maintain correct fit and function

What's included:

• One wiring harness assembly

Install notes:

• Disconnect power to the appliance before attempting any repair to avoid shock or injury
• Compare connectors and routing with the original harness to ensure correct replacement
• Handle connectors carefully; do not force mismatched plugs and avoid pin damage
