Frigidaire 5304516209 Wiring Harness (Main) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304516209 replaces AP6837970, 5304493653.

Description

This wiring harness connects control components and delivers reliable electrical routing inside the appliance, restoring proper circuit continuity and helping eliminate intermittent power or control issues. What it does

• Provides the required wiring and connector plugs between controls, switches and motors
• Restores lost or damaged electrical paths that cause intermittent operation or non-responsive controls
• Replaces harnesses with frayed wires, damaged insulation or broken terminals to reduce short and fault risks
• Ensures correct plug-to-plug connections for safe, consistent appliance function

What's included One wiring harness Install notes

• Disconnect power to the appliance before starting any repair
• Verify connector orientation and fully seat plugs to avoid loose connections
• Route harness away from sharp edges and heat sources; secure with existing clips or fasteners
• If wires or terminals appear damaged beyond visible repair, replace the entire harness.
