Frigidaire 316001208 Wiring Harness (Main) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316001208 replaces AP3214689, 948929, AH734994, EA734994, PS734994.

Description

This main wiring harness connects a refrigerator's control board and key components, providing organized power and signal routing so controls, lights and the compressor operate reliably. Replaces a damaged or burned main harness for restored electrical continuity. What it does

• Routes power and signal connections between the control board, lights, compressor and sensors.
• Prevents intermittent operation caused by loose, corroded or broken wiring.
• Can stop failures such as no lights, components not running, or control errors when the harness is the fault.
• Keeps wires organized and secured to avoid chafing and shorting.

What's included

• One main wiring harness as pictured.

Install notes

• Disconnect power before servicing to prevent shock or damage.
• Compare the new harness to the original and route wires the same way; replace any damaged clips or grommets.
• Reconnect all terminals fully; loose connectors can cause intermittent faults.
