Best Seller
Manufacturer Part

Frigidaire 316001225 Wiring Harness (Main) OEM Part

Manufacturer's Part Number: 316001225
Genuine Frigidaire part
Appliance Compatibility Tool
$23.26

Secure and trusted checkout with

Out Of Stock

Usually ships within 4 - 14 days

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316001225 replaces AP2123555, 832779, AH436235, EA436235, PS436235.

Description

This main wiring harness routes power and control signals between an appliance's control board and its components so switches, sensors and motors can operate reliably. It replaces a damaged or faulty harness to restore proper electrical connections. What it does:
  • Provides factory-style connector plug-and-play connections between control electronics and components
  • Replaces frayed, burned or broken wiring that can cause intermittent operation
  • Restores lost or intermittent power to controls and motors when harness damage is the cause
  • Helps eliminate blown fuses or tripped breakers caused by shorted or exposed wires
What's included: One main wiring harness (as pictured) Install notes:
  • Disconnect all power (unplug appliance or shut off breaker) before starting any work
  • Compare connectors and wire routing to the original harness to ensure correct fit
  • Route harness along original clips and retainers; avoid sharp edges and hot surfaces
  • Inspect connectors for corrosion; secure with cable ties as needed and test appliance after reconnection

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Frigidaire 316001225 Wiring Harness (Main) OEM Part

Part Number:
OEM6370674
Manufacturer's Part Number:
316001225

Fits 14 models

ManufacturerModel NumberDescription
FrigidaireFGF335CGSKGas Range
Kenmore / Sears790.71022101GAS RANGE
Kenmore / Sears790.71022102GAS RANGE
Kenmore / Sears790.71102004GAS RANGE
Kenmore / Sears790.71107004GAS RANGE
FrigidaireFGF324BHWDGas Range
FrigidaireFGF324WHSDGas Range
FrigidaireFGF326WGSJGas Range
FrigidaireFGF345BHWCGas Range
FrigidaireFLF335CHSAGas Range
FrigidaireFLF335CHSBGas Range
FrigidaireFLF335CHSCGas Range
FrigidaireFLF335CHTAGas Range
FrigidaireFLF335CHTBGas Range
