Ge WB27T11356 Electronic Control Board (Merlin3) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB27T11356 replaces AP5646440, 3026136, PS5135628.

Description

This electronic control board assembly (Merlin3) is the appliance's central controller. It interprets keypad inputs, drives the display, and communicates with the control system to execute cooking functions—restoring dependable operation when the original board fails.

• Interprets touchpad/key commands and updates the display
• Communicates with the appliance's control system to run selected modes and cycles
• Helps coordinate timing and temperature based on sensor feedback
• Typical failure symptoms: blank or flickering display, unresponsive controls, error codes, or the oven not starting/heating

What's included: 1 electronic control board assembly (Merlin3) Install notes:

• Disconnect power at the breaker/fuse box and verify no voltage is present before servicing
• Use ESD protection; handle the board by the edges to avoid component damage
• Photograph/label all connectors; move wires one at a time to the new board
• After reassembly, restore power and follow the model's tech sheet for any required control reset or self-test
