Ge WD12X10198 Spray Arm Bracket (Mid) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Support.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD12X10198 replaces AP3883836, 1168264, AH1019469, EA1019469, PS1019469, WD12X10402.

Description

Mid spray arm bracket that secures the middle spray arm inside the dishwasher tub, keeping the arm aligned so it can rotate freely and deliver water for thorough cleaning. What it does:

• Holds the middle spray arm in position so it can spin and distribute water across the load.
• Maintains proper spray-arm alignment to help restore even cleaning coverage.
• Common symptoms: spray arm droops, wiggles, becomes detached, makes noise, or fails to rotate.
• Replaces a worn or broken support bracket that can interfere with spray-arm operation.

What's included: One mid spray arm bracket. Install notes:

• Disconnect power to the appliance (turn off breaker) before servicing.
• You may need to remove the lower/upper rack and the spray arm to access the bracket.
• Handle small clips and sharp edges carefully; inspect adjacent parts for wear while replacing.
