Ge WD01X20332 Door Balance Cable Assembly (Dishwasher) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Cable Or Retainer.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD01X20332 replaces AP5809952, 3453311, PS9494475.

Description

This is the door balance cable assembly for a dishwasher. It links the door hinge to the tension spring so the door opens smoothly and stays balanced, helping prevent a heavy or slamming door.

• Connects the door hinge to the spring to counterbalance door weight
• Helps the door open/close smoothly and stay in position
• Common failure symptoms include a door that drops quickly, feels heavy, or won't hold half-open
• A snapped or frayed cable may be visible near the lower side of the cabinet

What's included: One cable assembly. Install notes:

• Disconnect power and shut off water before servicing
• Support the door and use caution—hinge springs are under tension
• Note the original cable routing over pulleys and through guides; reinstall the same way
• Some models use a cable on each side; check your model and order quantity as needed
