Ge WD16X10001 Cam Timer (Mechanical Drive Timer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Bumper, Bushing, Grommet.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD16X10001 replaces AP2039389, 270920, AH259447, EA259447, PS259447.

Description

This cam timer is the mechanical control that sequences an appliance's cycles, restoring correct timing and function when the control knob stops advancing. Replace a worn or stuck timer to recover proper cycle progression and operation. What it does:

• Advances cycle stages by rotating cams that open and close control contacts
• Sends timed signals to motors, switches and circuits to start and stop functions
• Common symptom: cycles won't advance or unit stays stuck in one cycle
• Common symptom: timer won't turn or control knob feels loose/slips

What's included:

• One replacement cam timer assembly

Install notes:

• Disconnect power before servicing to avoid shock or injury
• Access usually requires removing the control console or rear panel; use proper tools
• Note original timer position and knob alignment before removal for correct reassembly
• Test appliance through a full cycle after installation to ensure proper operation
