Ge WD21X28004 User Interface Board (8-Button, Configured Service) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X28004 replaces AP7014272, WD21X28421, WD21X28605.

Description

This user interface board fits dishwashers with an 8-button control panel. It interprets button presses and illuminates the panel, relaying your selections to the main control so cycles start and run as expected. What it does:

• Reads button inputs and powers the panel indicators
• Communicates selections to the main control to initiate/manage cycles
• Restores responsive controls when keys don't work or lights are dark
• Helps address no-start, erratic panel behavior, or only some keys working

What's included:

• 1 configured 8-button user interface board

Install notes:

• Disconnect power at the breaker before servicing
• Use ESD protection and handle the board by its edges
• Note ribbon cable/connector positions; take photos to guide reassembly
• Transfer any panel, bracket, or overlay components from the original as required
