Ge WB27T11288 Oven Control (Electronic Control Board) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB27T11288 replaces AP4980386, 1810660, AH3486652, EA3486652, PS3486652, WB27T11320.

Description

• Controls oven heating cycles, bake and broil functions, and temperature regulation
• Manages oven timing and display readouts for set cook times and delays
• Replaces a non-responsive or erratic control board causing incorrect temperatures or unresponsive controls
• Works with the oven's control harness and user interface to send power to heating elements

• Disconnect power to the appliance at the breaker before servicing
• Handle the control by the edges and avoid touching circuitry; use anti-static precautions if available
• Verify connector orientation and seat all harnesses fully during reassembly
