Ge WE01X27781 Door Switch (Dryer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WE01X27781 replaces AP6889018.

Description

This door switch confirms the dryer door is closed so the appliance can start and run. Replacing a worn or failed switch restores safe operation by preventing the drum and heater from operating with the door open.

• Senses the door open/closed position and signals the control/start circuit
• Enables the motor and heat only when the door is fully closed
• Typical failure symptoms: dryer won't start, must hold the door to run, or stops when the door is moved
• Drum light stays on or off incorrectly when the door is opened/closed

What's included: Includes one door switch. Install notes:

• Disconnect power to the dryer before servicing
• Access the switch from behind the front panel or top cover, depending on model; remove mounting screw(s) or release locking tabs
• Transfer the wire connectors to the new switch one at a time to maintain placement
• Ensure the actuator "clicks" with door movement and test operation before reassembly
