Ge WB30X26465 Radiant Surface Element (Haliant, 8-Inch) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB30X26465 replaces AP6034290, WB30K10013, 4453014, PS11766620.

Description

This 8-inch Haliant radiant surface element mounts beneath the glass of a smooth-top range to heat a single cooking zone. Replacing a failed element restores proper heating response and consistent performance on that burner. What it does:

• Heats the 8-inch cooking zone by converting electrical energy to radiant heat beneath the glass
• Helps provide even heating and smooth simmer-to-boil control
• Works with the surface control to cycle and maintain the set temperature
• Typical failure symptoms: no heat, very slow heating, or inconsistent/uneven heating on that burner

What's included:

• 1 Haliant 8-inch radiant surface element

Install notes:

• Disconnect power at the breaker; allow the cooktop to cool fully
• Lift/remove the glass top per your model's procedure to access the element
• Note wire locations and transfer any mounting clips/brackets from the old element if needed
• After reassembly, test the burner; if it still won't heat, the surface element switch/control may be at fault
