Jeffrey E Plymouth , MN September 03, 2016 Appliance: Model PSA9120SF1SS Selector knob stopped functioning Replaced the "Encoder Board". My GE Advantium control panel came of fairly easily. There was 2 screws on top to remove a vent director giving access to a single screw that held the control panel in place. Once I removed that screw, I had to slide the control panel upwards by about 1/2" before it came off. At this point, I took several photographs of the wire connections to make sure I could reassemble them correctly... there were many! After unplugging the wire harnesses and connections, I had to separate 2 main control boards that were attached by a series of copper pins (probably 22 or so). Finally, under the 2 control boards I was able to access and replace the Encoder Board. After putting everything back together, it worked like new. Since this part only lasted 2 years, I'm guessing that I will have to replace it several times over the life of the appliance. Read More... 8 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Brian E Commerce City , CO October 27, 2020 Appliance: General Electric Microwave Hood Combo PSA9120SF1SS Dial function didn’t work on my GE advantium 120 convection/microwave Removed control panel from microwave, took pictures of the connections. Removed a circuit board(4 screws) and moved another one out of the way(2 screws). 3 screws held the Encoder board in and one small electrical harness. Take your time and it won’t be a problem. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Jeffrey O Anthem , AZ April 22, 2016 Appliance: General Electric General Electric CSA1201RSS02 Encoder board rotary control not functioning Took off the control panel dissected all the boards to access the encoder board and replaced it easily. All is now working again perfectly. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
Sandra Y Hinckley , MN August 06, 2023 Appliance: Model PSA91205F4SS Knob 0n microwave did not change settings. Ordered part, encoder interface board, and husband replaced in 15-30 minutes. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Jeffrey E Plymouth , MN January 15, 2019 Appliance: Model GE ADVANTIUM MICROWAVE Selector dial didn't work Replaced it. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
