Doug C Staunton , VA February 18, 2015 Appliance: Model JKP 13 BOD 1BB The convection fan on my ge profile convection wall oven burned out The motor hummed but the fan didn't turn. Clearly the brushes were burned out. I ordered a new fan, although I had to talk to a human at ApplianceParts because my model was not listed. The part was a perfect fit. The only problem is determining how to remove the over to reach the back, no instructions anywhere online. But trial and error eventually worked. You absolutely need a nut-driver that fits the hex head screws on the oven to remove panels covering the motor, but a cheap screwdriver with multiple heads used without the heads may work. Oven works perfectly now. Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers
John L Mchenry , IL January 04, 2019 F2 code and lower oven not turning on Took control board in to be rebuilt to appliance pros. Now works perfectly. Was returned in one working day Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Bart T Wake Forest , NC May 11, 2020 Appliance: Kenmore 30" Electric Built-In Oven 91149023100 Convection fan motor failed on my 30 inch in wall oven. I ordered the replacement part from AppliancePartsPros.com and replaced the part. Straight forward to remove the oven out of the wall ( 4 screws and slide out). The trick part was supporting the oven while removing and replacing the motor. I used (4) automotive jack stands set to the appropriate level with two 24x24 inch boards across to support. The other note is that the nut that holds the fan blade to the motor is a left-hand thread. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers, Wrench Set
