Ge WB27T11200 Glass Touch Assembly (Stainless Steel) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Touch Pad.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB27T11200 replaces AP4484297, 1556103, AH2370122, EA2370122, PS2370122.

Description

This glass touch assembly is the stainless front user-interface panel for the oven controls. It replaces a worn, cracked, or unresponsive touch keypad so you can select modes and temperatures and operate your appliance reliably.

• Provides the touch-sensitive keys for cooking modes, temperature, timer, and light functions
• Sends user inputs to the electronic control; failure can prevent starting or adjusting the oven
• Common symptoms: some keys don't respond, random beeping or key error codes, unable to set temperature
• Restores appearance when the front control glass is scratched or cracked

Includes: 1 glass touch control assembly in stainless finish. Install notes:

• Disconnect power at the breaker before servicing
• Support the panel and handle glass carefully; remove trim and mounting screws
• Move ribbon/plug connectors one at a time to the new assembly; avoid creasing flex cables
• Reinstall hardware and test all touch keys before final reassembly
