Ge WR23X10776 Door Switch Harness (Wiring Harness) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR23X10776 replaces AP5796128, 3032824, PS8758464.

Description

This door switch harness connects the door switch to the cabinet wiring to restore proper door-open/close signaling. It replaces a damaged or worn harness to help the appliance detect door position and enable interior lights or control features. What it does:

• Provides the electrical connection between the door switch and appliance wiring harness
• Restores interior light and control responses when the door opens or closes
• Replaces frayed, cracked, or disconnected wiring that can cause intermittent power or no light
• Helps eliminate clicking, dead lights, or controls that don't respond to door position

What's included:

• One door switch wiring harness

Install notes:

• Disconnect power before beginning any repair to avoid shock; this is a high-priority safety step
• Handle connectors carefully; match connector shapes and wire colors when replacing
• May require removal of door gasket or inner door panel depending on appliance model
