Ge WR55X22872 Mechanical Control Harness (Timer Wiring Harness) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR55X22872 replaces AP6004965, 4468432, PS11737071.

Description

This mechanical control harness connects the appliance's mechanical timer/control to switches and motors, restoring reliable signal and power routing for timed cycles. Helps re-establish proper control function when wiring is damaged or worn. What it does

• Routes power and control signals between the mechanical timer and associated switches/components
• Restores electrical continuity when original harness has broken wires or failed connectors
• Can resolve symptoms such as intermittent or no timer advancement, loss of specific functions, or components not receiving power
• Designed to match OEM connector locations and wire lengths for direct replacement

What's included One mechanical control harness. Install notes

• Disconnect power to the appliance before inspecting or replacing the harness.
• Compare the replacement harness to the original to confirm connector types and routing before installation.
• Handle connector terminals gently; avoid pinching or over-bending wires during routing.
