Ge WR23X26120 Valve Harness (Wiring Connector) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR23X26120 replaces AP6024781.

Description

This replacement valve harness connects the refrigerator's water/ice valve to the appliance wiring, restoring the electrical connection needed for proper valve activation and water dispensing. Use it to replace a damaged or corroded valve connector harness. What it does:

• Provides the electrical connection between the main wiring and the water/ice valve
• Enables the valve to open when dispenser or icemaker signals are sent
• Replaces damaged, burnt, corroded, or loose wiring that can cause intermittent or no water/ice flow
• Prevents poor connections that can lead to arcing or failure to dispense

What's included: One valve harness Install notes:

• Disconnect power to the appliance before starting; turn off the water supply if working near water lines
• Remove the appropriate access panel to reach the valve and harness; note connector orientation for reassembly
• Disconnect old harness connectors, route and secure the new harness to avoid pinching or contact with sharp edges
• If terminals show damage or corrosion beyond the harness, inspect valve and harness mating surfaces and replace damaged components
