Ge WB18T10544 Harness, Main Top (Right) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB18T10544 replaces AP5781593, 3025699, PS8690571.

Description

This right-side main top wiring harness routes power and control signals to the cooktop's switches, burners and ignitors so the surface elements operate reliably. It replaces a damaged or worn top harness to restore proper electrical connections. What it does

• Carries power and signal between the console/switches and right-side surface elements or igniters.
• Enables ignition and heat control for the right-side burners when intact.
• Commonly associated with symptoms like a non-working or intermittent right burner, no spark/ignition at the right surface element, or visible burned/damaged wires.
• Replaces a faulty harness that shows frayed wires, melted insulation, or loose/broken connector pins.

What's included

• One right-side main top wiring harness (WB18T10544) as shown.

Install notes

• Disconnect power at the breaker or range plug before starting any work.
• Handle connector pins carefully; match and seat each connector fully to ensure reliable contact.
• Route and secure the harness following the original path; replace any mounting clips or grommets if worn.
