Ge WB44K10019 Bake Element (Lower Oven) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB44K10019 replaces AP3868848, 1167687, AH1021507, EA1021507, PS1021507.

Description

This lower oven bake element provides the primary heat source for Bake cycles, restoring proper preheat and even, reliable cooking. Replace it if the oven won't heat, preheats slowly, or bakes unevenly.

• Heats from the bottom in Bake to reach and maintain set temperature
• Common symptoms: no heat in Bake, very slow preheat, oven temperature too low, or uneven results
• Visual clues: cracks, blisters, or burned spots on the element sheath
• If shorted, it may trip the circuit breaker when Bake is selected

What's included: 1 bake element Install notes:

• Disconnect power at the breaker and let the oven cool completely
• Remove racks, take out the element's mounting screws, and gently pull the element forward
• Hold wires so they don't retract; transfer and firmly connect the terminals; replace any heat-damaged connectors
• Reinstall element, ensure it's not contacting the cavity, restore power, and test Bake
