Ge WR13X27091 Top Hinand Pin Assembly (Refrigerator Door) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR13X27091 replaces AP6286485, WR13X21172, 4589788, PS12344829.

Description

This top hinge and pin assembly supports the refrigerator door at the upper corner and provides the pivot point for smooth opening and closing. Replacing a worn hinge restores proper alignment and a consistent, reliable door seal.

• Supports door weight at the top and provides the pivot for smooth swing
• Maintains door alignment to prevent rubbing and uneven gaps
• Helps the door close securely for proper gasket contact
• Typical symptoms: door sags or scrapes, doesn't close flush, binds/clicks at the top, visible wobble

What's included: One upper hinge bracket with integrated pivot pin. Install notes:

• Disconnect power and remove items from the door shelves
• Have a helper support the door; remove the top hinge cover and mounting screws, then lift the door straight up/off
• Position the new hinge, secure with the original hardware, and set the door back on the pins
• Adjust leveling if needed before restoring power
