Ge WH12X10544 Interface Board (Washer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH12X10544 replaces AP5657442, 2332542, PS6011703.

Description

This interface board mounts behind the washer's control panel and reads your button/knob inputs. Replacing a failed UI board restores responsive controls, correct cycle selection, and indicator lights so the washer can start and run as expected.

• Interprets user inputs from the control panel and selector(s)
• Communicates selections to the main control to run chosen cycles/options
• Drives status lights or display during operation
• Typical failure symptoms: unresponsive controls, lights/display not illuminating, cannot start or change cycles, intermittent/erratic inputs

What's included: 1 interface board Installation notes:

• Disconnect power to the appliance before servicing; follow ESD precautions and handle the board by the edges
• Access the board by removing the console/control panel; note screw locations and take photos of wiring
• Transfer wire connectors one at a time to the new board to prevent miswiring; ensure all harnesses are fully seated
• Reassemble the console and restore power; test all buttons and indicators
