Ge WR55X10786 Dispenser Interface Assembly (Ice/Water Control) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Touch Pad.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR55X10786 replaces AP4363233, 1477918, AH2340412, EA2340412, PS2340412, WR55X10718.

Description

This dispenser interface assembly restores the electronic user interface for your refrigerator's ice and water dispenser. It reads button selections and sends commands to the dispenser system, helping resolve a dead display or unresponsive dispenser controls.

• Manages ice/water selection, dispenser lighting, and lock functions
• Interprets button presses and signals the auger motor, water valve, and related control circuits
• Failure can present as no response from buttons, no backlight/display, inability to switch cubed/crushed ice, or intermittent operation
• Replacing a failed interface can restore normal dispenser control

What's included: 1 dispenser interface assembly Install notes:

• Disconnect power to the refrigerator before servicing
• Remove dispenser trim carefully and access mounting screws to reach the interface
• Transfer wire harness connectors one at a time, matching orientation to avoid miswiring
• Handle the electronics with care; avoid static discharge and verify door switch/lever alignment before reassembly
