Ge WR2X9135 J-Trap (Drain Elbow) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR2X9135 replaces AP2060688, 299240, AH299554, EA299554, PS299554, WR02X9135.

Description

This molded J-shaped drain elbow channels defrost and condensation water from the evaporator area to the refrigerator drain system, helping prevent pooling and water leaks inside the fresh food compartment. What it does

• Directs defrost/condensation water into the drain system to prevent standing water under the evaporator.
• Guides flow from the evaporator cover or drain trough to the main drain tube or pan.
• Common symptoms of a failing J-trap: water pooling inside the refrigerator, leaks at the front lower area, or slow drainage from the evaporator area.

What's included

• One J-trap drain elbow.

Install notes

• Disconnect power before servicing and allow the evaporator area to thaw if iced.
• Remove applicable interior panels or evaporator cover to access the drain path.
• Inspect mating seals and surrounding drain tubing; replace if cracked or degraded to ensure a tight fit.
• Reassemble panels and restore power; run a short defrost or pour small amount of water to confirm proper drainage.
