Ge WB36X10294 Lamp Drawing (Lighting Assembly) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Microwave Light, Bulb, Lamp.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB36X10294 replaces AP3793483, 1087390, PS955656, WB36X10198.

Description

This lamp drawing is the appliance lighting assembly that provides interior illumination for safe visibility and operation. It restores proper lighting so you can check contents and settings without opening the appliance in the dark. What it does

• Houses and positions the interior lamp to produce even light where needed.
• Connects to the appliance wiring to deliver power to the lamp.
• Commonly replaces assemblies that are cracked, broken, loose, or no longer illuminating.
• Resolve symptoms such as dim, flickering, or non-working interior lights.

What's included

• One lamp drawing lighting assembly.

Install notes

• Always disconnect power (unplug or shut off breaker) before accessing electrical components.
• Handle lamp sockets and wiring gently to avoid damage; replace bulbs per manufacturer specifications.
• Verify fit and connector type before installation.
