Ge WH01X10680 Lid Lock Bezel (Washer), 1 OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH01X10680 replaces AP5781551, 3029685, PS8690650.

Description

This lid lock bezel is the molded trim that snaps into the washer's top panel opening and holds the lid lock in place. Replace a cracked or missing bezel to keep the lock secure and ensure consistent lid-closed detection during cycles.

• Secures and aligns the lid lock within the top panel opening
• Covers the cutout for a finished look and protected edges
• Helps prevent the lock from wobbling or falling through the opening
• Common signs of failure: broken/missing bezel, loose lid lock, intermittent "lid open" errors, or cycles that won't start because the lock can't seat

What's included: 1 lid lock bezel Install notes:

• Disconnect power and water supply before service
• Lift or hinge the top panel per model instructions to access the lock from below
• Detach the lid lock from the underside, release the old bezel tabs, and remove
• Snap in the new bezel, reinstall the lock with proper orientation, and test operation
