Ge WH01X23494 Door Lock Module (Washer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH01X23494 replaces AP5983868, 4396420, PS11721792, WH01X10752.

Description

This door lock module secures the washer door during operation and communicates door status to the control board. Replacing a failing lock restores safe cycle starts, consistent spinning, and proper unlocking when the cycle completes. What it does:

• Locks the door at the start of a cycle to prevent opening mid-wash
• "door closed/locked" so the control can fill, wash, and spin
• Releases the door when it's safe at the end of the cycle
• Common failure symptoms: washer won't start or spin, door won't lock/unlock, intermittent pausing, or a "door/lock" indicator on the display

What's included:

• 1 door lock module

Install notes:

• Disconnect power before servicing; turn off water if you'll move the appliance
• Access the lock from the front by loosening the door boot clamp and removing the lock's mounting screws
• Label and transfer the wire connectors to the new module; reuse original hardware
• Refit the door boot fully and run a short test cycle to proper locking and release
