Ge WH08X36340 Main Wiring Harness (Front-Load Washer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH08X36340 replaces AP7217742.

Description

This main wiring harness connects the control assembly to motors, valves, sensors and other components on a front-load washer, restoring electrical communication for normal operation and control response. What it does:

• Carries power and signals between the control board and washer components (motor, valves, sensors, door lock)
• Replaces damaged or chafed wiring that can cause intermittent operation or component failures
• Can resolve symptoms like a washer that won't start, unresponsive controls, or certain functions not working
• Helps restore reliable circuit routing when connectors are corroded or wires are broken

What's included:

• 1 main wiring harness

Install notes:

• Disconnect power at the breaker or unplug the washer before beginning work
• Handle connectors carefully; match keyed plugs and route harness along original clips and channels
• Inspect connectors and mating terminals for corrosion or damage and replace if necessary
