Ge WD21X30864 Main Control Board (With Enclosure) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X30864 replaces AP7198307.

Description

This main control board with enclosure replaces the appliance's electronic oven controller and restores control of bake, broil and display functions. It provides the circuit and connectors the range uses to manage temperature and user inputs. What it does:

• Receives user commands and runs oven bake/broil cycles through the control relays
• Powers and drives the front display and touchpad interface
• Helps regulate temperature by switching heating elements based on sensor input
• Common symptom fix: oven not heating, display blank or unresponsive, or control clicks and won't start a cycle

What's included:

• One main control board mounted inside an enclosure

Install notes:

• Disconnect power at the breaker before starting any work to avoid shock hazard
• Handle the board by its edges and avoid contact with circuit traces or components
• Note and photograph connector locations before disconnecting so wiring is reattached correctly
