Ge WR07X10133 Compressor Start Relay And Overload (Ptc) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Relay, Overload, Capacitor.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR07X10133 replaces AP4981422, 1812124, AH3487744, EA3487744, PS3487744.

Description

This assembly mounts on the refrigerator compressor and combines the PTC start relay with a thermal overload protector. It helps the compressor start reliably and cuts power if overheating occurs to protect the motor and maintain cooling performance.

• Supplies initial start current to the compressor via the PTC relay
• Opens on overcurrent/overheat to prevent compressor damage
• Common failure symptoms: compressor won't start, repeated clicking/buzzing from compressor area, warm refrigerator/freezer, short cycling
• Useful when the original start device is burned, cracked, or rattles when shaken

What's included: One PTC start relay with integrated overload protector Install notes:

• Disconnect power and allow the compressor area to cool before servicing
• Remove the terminal cover, note wire locations, and pull off the old start device
• Push the new start device fully onto the compressor pins and reconnect wires per the wiring diagram
• If your model uses a run capacitor, transfer/reconnect it as directed and reinstall the cover before restoring power
