Ge WP20X21957 Overload (Compressor Protector) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP20X21957 replaces AP6280153.

Description

This compressor overload protects the refrigerator compressor by interrupting power during motor overheating or electrical faults, helping prevent damage and repeated starter failure. It's a small, replaceable device used with the compressor start components. What it does:

• Protects the compressor by cutting power if the motor overheats or draws excessive current
• Works with the start relay/capacitor to help the compressor start reliably
• Commonly replaces a failed overload that causes the compressor not to run or to click repeatedly
• Helps prevent further compressor damage from repeated overheating events

What's included: One overload Install notes:

• Disconnect power to the appliance before servicing to avoid shock or injury
• Inspect the start relay and wiring when replacing the overload; replace damaged components
• Mount and connect the overload exactly as the original; verify proper seating on compressor terminals
