Ge WR02X11121 Pin, Mid Hin(Door Hinpin) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Hinge.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR02X11121 replaces AP3670726, 913126, AH285490, EA285490, PS285490, WR2X11121.

Description

This mid hinge pin secures the refrigerator door to the mid hinge assembly, helping the door pivot smoothly and stay aligned. Replaces a worn or bent hinge pin to reduce door binding and uneven closing. What it does:

• Acts as the pivot point between the door and mid hinge, enabling smooth door movement
• Restores proper door alignment when the original pin is worn or bent
• Helps stop door rubbing, sagging, or catching during opening and closing
• Works with the mid hinge and hinge bushing to maintain correct door clearance

What's included:

• One mid hinge pin

Install notes:

• Use basic hand tools; support the door before removing hinge hardware to prevent injury or damage
• Inspect hinge bushings and hinge surfaces; replace any worn components for best results
• Disconnect power and remove food from door area as needed for safe handling
