Ge WR01X46445 Pressure Sensor And Hose (Assembly) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR01X46445 replaces AP7225376, WR01X42889, WR01X42890, WR02X38937, WR55X42894.

Description

This pressure sensor and hose assembly senses pressure changes and sends a signal to the refrigerator control to help the dispenser/ice/water systems operate correctly. Replaces a damaged or leaking sensor/hose for reliable system feedback. What it does:

• Detects pressure/vacuum changes and reports them to the control board so the appliance can manage dispenser and ice/water functions
• Commonly used when the dispenser or ice system behaves intermittently or shows pressure-related error codes
• Helps prevent false sensor readings caused by cracked or clogged tubing
• Restores a secure hose connection and sealed sensor input when the original is damaged

What's included: One pressure sensor with attached hose assembly Install notes:

• Disconnect power (and water supply if applicable) before starting work
• Handle the hose and sensor gently to avoid kinks or damage; trim only if explicitly required by OEM instructions
• Verify connector orientation and seating; ensure hose route is free from pinches
