Ge WH12X10530 Water Level Pressure Switch (Electronic) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH12X10530 replaces AP5671390, 3029850, PS7320331, WH12X10587.

Description

This electronic water level pressure switch senses air pressure from the wash tub and tells the control when to start and stop filling. Replacing a failed switch restores proper fill levels and helps cycles advance reliably. What it does:

• Monitors tub water level via an air hose connected to the switch
• Signals the control to start/stop the inlet valves at the correct level
• Enables cycle progression by confirming empty/full status
• Common symptoms: won't stop filling, stops filling too soon, incorrect water level, or water-level error codes

What's included:

• 1 electronic pressure switch

Install notes:

• Disconnect power and turn off water supply before servicing
• Access the switch in the control console or rear cabinet area (location varies by model)
• Move the pressure hose and wire connector(s) over one at a time; ensure airtight hose fit and proper routing without kinks
• Inspect the hose and air dome for cracks, kinks, or blockages; clear or replace if needed
