Ge WR07X10086 Ptc Relay (Start Device) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Relay, Overload, Capacitor.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR07X10086 replaces AP3796509, 1091641, AH963838, EA963838, PS963838.

Description

PTC relay is a start device that helps the appliance motor begin turning by providing a brief boost to the start winding. Replacing a faulty relay restores reliable motor starting and can return normal operation. What it does:

• Provides a temporary start assist to the motor's start winding so the motor can overcome initial inertia.
• Commonly replaced when the motor hums but won't start or when the unit fails to begin operation.
• Can address symptoms such as clicking noises at startup, intermittent motor starting, or no motor movement despite power.
• Works as the motor start control — failure can prevent the appliance from operating properly.

What's included: One PTC relay. Install notes:

• Disconnect power before servicing to avoid electric shock.
• Note terminal locations and orientation before removal; install replacement on the same terminals.
• Handle terminals gently and ensure tight, corrosion-free connections.
• After installation, restore power and verify the motor starts and runs normally.
