Ge WB49K10046 Broil Shield (Oven Broiler Heat Shield, 1 Pc) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB49K10046 replaces AP6040940.

Description

This broil shield is a replacement oven part that protects the oven interior from direct broiler heat and splatter, helping prevent damage to the oven cavity and nearby components. It's a direct-fit shield used behind the broil element. What it does:

• Deflects direct broiler heat away from the oven back panel and insulation
• Protects the oven cavity from grease and food splatter during broiling
• Helps prevent warping or damage to interior panels caused by concentrated heat
• Replace when the shield is warped, dented, corroded, or missing to restore proper protection

What's included:

• One broil shield (one piece as shown)

Install notes:

• Ensure the oven is completely cool and power (and gas, if applicable) is disconnected before starting
• Handle carefully — edges may be sharp; use gloves to protect hands
• Verify correct orientation and secure mounting hardware during installation
