Ge WB13K10031 Spark Module (6-Point) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Spark Module.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB13K10031 replaces AP4380300, WB13X27503, WB13K10038, 1473629, AH2344294, EA2344294, PS2344294, WB20X10034.

Description

This six-point spark ignition module for gas cooktops/ranges converts line voltage into high-voltage pulses that fire the burner igniters. It restores consistent, reliable lighting across multiple burners when you turn a knob.

• Distributes high-voltage pulses to up to six surface-burner igniters when a burner switch is turned on
• Helps resolve no spark/click on all burners, no spark on some burners, intermittent ignition, or continuous clicking
• Replaces a module that produces weak, erratic, or no spark
• Ignition control only; it does not regulate gas flow or flame size

What's included: 1 spark module Install notes:

• Disconnect power and shut off gas before servicing
• Photograph and label all wires; transfer them one at a time to the matching terminals (six HV outputs plus power/ground)
• Mount securely in the original location and keep connections dry; after installation, ensure burner caps are seated and igniters are clean
