Robert C San Antonio , TX December 04, 2017 Appliance: General Electric Electric Range ABS300J3WW The 8 inch burner would not turn off had to unplug appliance it melted terminal block I ordered new burner. New terminal block and new switch. Unplug appliance. Removed switch panel. Had 6 star screws and two Philips head screws. Removed switch and remember to keep all screws because you need to reuse them. Also suggest taking a picture of wiring so you remember were to plug them back in on switch. All in all. It's a very easy fix. You can save yourself literally a hundred or more dollars. By doing it yourself. As you remove old parts keep in mind how you did it and then you will remember how to install new parts and your done. The only hick up on this project which is no big deal. Was the length of wire that came with new terminal block. Several inches to long. It needs to be tucked up and or zip tied out of the way from the burner in the back of stove top. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Willy S Aurora , CO January 23, 2016 Stove needed new drip pans and burner elements Unplugged element from connector, removed elements and drip pans. Replaced them in reverse order making sure the element sat in the drip pan level. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes
