Ge 31-3028 Tech Sheet (Service And Wiring Diagram) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Manual, Care Guide.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 31-3028 replaces AP4693160, 031-3028, AH3415917, EA3415917, PS3415917.

Description

This tech sheet is the factory service information insert that gives technicians quick access to wiring diagrams, diagnostics, and critical service info to troubleshoot and repair the appliance more efficiently. It's a compact reference useful during service calls. What it does:

• Provides wiring diagrams and electrical schematics for accurate troubleshooting
• Lists common diagnostic procedures and error descriptions to help isolate faults
• Shows component locations and basic service notes to guide repairs
• Summarizes key parts and connections referenced during repairs

What's included: One printed tech sheet as shown Install notes:

• No tools required to use; store near the appliance or inside service panel while working
• Keep the sheet dry and free of grease to preserve legibility
• Not a replacement for full service manual; follow all safety and lockout procedures before servicing
• If wiring is changed or replaced, verify connections against the diagram before reapplying power
