Ge WD21X10077 Timer (Electromechanical) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X10077 replaces AP2039748, 165D4779P105, 824338, AH260132, EA260132, PS260132, WD21X10103.

Description

This electromechanical timer controls cycle selection and timing for your appliance, restoring proper step progression and cycle operation. It replaces a worn or failed timer to help get your appliance cycling again. What it does

• Advances and times wash/dry cycles based on the selected program.
• Re-establishes cycle control when the timer motor or cam contacts fail.
• Commonly used when cycles won't advance, the appliance won't start a timed cycle, or settings don't change.
• Works as the user-operated timing/control mechanism for mechanical cycle selection.

What's included

• One electromechanical timer assembly.

Install notes

• Disconnect power before starting — shock risk. If the appliance is gas, also shut off the gas supply.
• Requires panel access and basic wiring knowledge; note wire locations or take a photo before disconnecting.
• Tighten fasteners and confirm wiring connections are secure; test operation with power restored.
