Ge WR08X21100 Compressor Start Device (Relay/Overload Combo) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR08X21100 replaces AP5986440, 4589654, PS11721884.

Description

This compressor start device attaches to the compressor to help it start and protect it from overheating. Replacing a failed device can help restore reliable compressor starts and consistent cooling.

• Provides the initial boost to start the compressor, then disengages
• Protects the compressor by opening the circuit on overcurrent/overheat
• Common symptoms of failure: compressor won't start, repeated clicking or buzzing from the rear, warm temperatures, short cycling
• Often shows heat damage or a burnt odor at the connector when failed

What's included: One compressor start device Install notes:

• Disconnect power and remove the rear access panel to reach the compressor
• Note wire locations and compressor pin orientation; take a photo before removal
• Push the device straight onto the compressor terminals until fully seated; replace any burnt connectors
• Restore power and verify smooth compressor start without repeated clicking
