Ge WD21X31720 Ui Harness (Control Panel) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X31720 replaces AP7194149.

Description

This UI harness connects the oven's control board to the user control panel so the display and buttons communicate reliably. Replacing a failed harness restores responsive touchpads and proper panel signaling. What it does:

• Carries signals between the control board and the user interface so button presses and display data transmit correctly
• Fixes symptoms like an unresponsive control panel or buttons that work intermittently
• Helps resolve a blank display or erratic display behavior when the harness is damaged
• Replaces a frayed, burnt or corroded cable that causes intermittent oven control faults

What's included: One UI harness as shown. Install notes:

• Always disconnect power (unplug or switch off circuit breaker) before starting work
• Handle connectors carefully; align pins and push fully until they seat to avoid bent terminals
• Route the harness along original clips and channels to prevent pinching or heat exposure
