Ge WB30K10014 Surface Element (8-Inch Coil) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB30K10014 replaces AP3868850, 1167348, AH1021348, EA1021348, PS1021348.

Description

This 8-inch surface element restores reliable heat to the large burner on an electric range. Replace a worn or open coil to bring back fast, even cooking performance and consistent temperature control.

• Heats cookware on the large 8-inch burner of coil-top electric ranges
• Common symptoms: burner won't heat, heats intermittently, or needs "wiggling" to work
• Visual clues: broken coil, blistering, hot spots, or arcing/burn marks at the terminals
• Helps ensure even heat distribution and stable pan support

What's included: 1 surface element Install notes:

• Disconnect power at the breaker and allow the element to cool completely
• Lift the old coil slightly and pull straight out from the receptacle
• Inspect the element receptacle and wiring for heat damage; replace if burnt before installing
• Align terminals and support feet, then push firmly until the element is fully seated
