Ge 031-13206 Wiring Diagram (Sheet) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number 031-13206 replaces AP4691586, 1814022, AH3412543, EA3412543, PS3412543.

Description

This wiring diagram is a printed schematic sheet that shows the appliance's electrical connections and component wiring. It helps identify wire colors, terminal locations, and circuit paths to support safe troubleshooting and repairs. What it does:

• Shows component locations, wire colors, and terminal numbering for accurate wiring reference
• Helps troubleshoot wiring faults, shorts, or incorrect connections during service
• Useful when the original diagram is missing, damaged, or unreadable
• Clarifies connector and harness routing to reduce miswiring risk

What's included: One printed wiring diagram sheet. Install notes:

• Disconnect power to the appliance before servicing electrical components
• Place or attach the diagram in an accessible location near the control area for future reference
• Use the diagram only as a reference; verify actual wiring and connections visually before reconnecting power
• Do not attempt repairs beyond your skill level.
