Lg 5075JJ1003K Ice Bucket Assembly OEM Part

Product Details

Genuine Lg part. See all items in Refrigerator Ice Bin, Bucket, Or Tray.

Cross Reference Information

Part Number 5075JJ1003K replaces AP5973069, 5075JJ1003E, 3379991, PS11706172.

Description

The Ice Bucket Assembly stores the ice produced by your refrigerator and feeds it to the dispenser. Replace a cracked or worn bucket to restore reliable ice storage and smooth, consistent dispensing.

• Holds and organizes ice in the freezer/ice compartment for dispensing
• Interfaces with the dispenser drive to move ice toward the chute
• Guides cubes during dispense to help minimize jams
• Damage may cause no or slow ice dispensing, loud grinding during dispense, or a cracked/broken bin or tabs

What's included: One ice bucket assembly. Install notes:

• Disconnect power to the refrigerator before servicing
• Open the ice compartment/freezer door and pull the existing bucket straight out; empty any remaining ice
• Align the drive connection and slide the new bucket fully into place until it seats
• Discard old ice, allow fresh ice to form, and test dispensing (cube/crush if available)
