Lg 2W20017F Outer Door Boot Clamp (Door Boot / Bellows Clamp) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number 2W20017F replaces AP4438435, 1266959, ACA32390102, AH3517813, EA3517813, PS3517813.

Description

Outer door boot clamp secures the washer's door boot to the front panel and tub, restoring the watertight seal and helping prevent the boot from shifting or separating during wash cycles. What it does:

• Clamps the outer edge of the door boot to the front panel to hold the bellows firmly in place.
• Helps maintain a watertight seal at the door—install when you see water leaking from the front or along the door seam.
• Replaces bent, corroded, or loose clamps that allow the boot to pull away or develop gaps.
• Works with the boot to reduce movement and rubbing that can cause premature wear or leaks.

What's included: One outer door boot clamp assembly. Install notes:

• Disconnect power and turn off water supply before beginning any repair.
• Access usually requires removing the washer door or front panel; drain the tub and remove the boot to fit the clamp correctly.
• Use appropriate pliers or a nut driver to secure the clamp; avoid excessive force that could damage the boot or mounting points.
• Inspect the door boot for tears or distortion; replace the boot if damaged to ensure a reliable seal.
