Lg ACV34326902 Damper Assembly (Refrigerator) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number ACV34326902 replaces AP5674984, 2655184, PS7787196.

Description

This refrigerator damper assembly opens and closes the air passage between the freezer and fresh food sections. Replacing a sticking or broken damper restores proper airflow and more stable temperatures, helping resolve warm spots or food freezing in the refrigerator.

• Regulates cold-air flow from the freezer into the refrigerator to maintain set temperatures
• Operates a flap within the air duct under control of the appliance's control system
• Helps reduce temperature fluctuations and improve overall cooling performance

What's included: 1 damper assembly Install notes:

• Disconnect power before servicing
• Access from inside the fresh food compartment; remove shelves and the damper/duct cover
• Remove mounting screws and disconnect the wire harness; transfer any foam seals or clips from the old unit if needed
• Seat the gasket evenly to prevent air leaks and route wiring away from the moving flap
