Lg 4901JK1001B Air Damper Assembly (With Motor) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number 4901JK1001B replaces AP4507559, 1335114, AH3583329, EA3583329, PS3583329.

Description

This air damper assembly regulates the flow of cold air from the freezer to the fresh food compartment. Replacing a worn or stuck damper restores proper airflow and temperature balance so groceries stay evenly cooled.

• Motorized flap opens and closes the air duct between compartments
• Helps maintain set temperatures and even cooling across shelves
• Common symptoms: refrigerator too warm while freezer is cold; items freezing in fresh food; clicking/buzzing near the damper; weak or no airflow from the vent
• Failure can result from a stuck door, worn gears, or a failed motor

What's included: One air damper assembly

• Disconnect power before servicing; do not work on live circuits
• Access from inside the refrigerator; remove shelves and the damper cover/grille
• Unplug the wire harness, release retaining tabs/screws, and transfer any seals or insulation if required
• After reassembly, restore power and ensure the damper cycles and airflow is present
