Lg EAU61524001 Fan Motor (Dc) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number EAU61524001 replaces AP5597606, 2666404, AH3644505, EA3644505, PS3644505.

Description

This DC fan motor drives the appliance's internal circulation fan to keep air moving where it's needed. Replacing a failing motor restores proper airflow and can resolve noise, non-running, or intermittent fan operation. What it does:

• Powers the fan that circulates air through the appliance and across coils
• Helps maintain stable temperatures by keeping airflow consistent
• Supports defrost performance by preventing stagnant, frost-prone areas
• Symptoms of failure include the fan not running, running intermittently, or making grinding/rattling noises

What's included:

• 1 DC motor

Install notes:

• Disconnect power before servicing; wear cut-resistant gloves
• Access the fan housing; remove covers/guards and clear any ice or obstructions
• Transfer the fan blade and any grommets/brackets from the old motor to the new one
• Note connector orientation; ensure the blade spins freely and clears the shroud before reassembly and testing
