Lg 6549W1S018C Turntable Motor (Synchronous) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number 6549W1S018C replaces AP4440102, 6549W1S008A, 6549WRS001U, PS3529223.

Description

This synchronous motor drives the microwave's glass turntable at a steady speed so food rotates for more even heating. Replace a weak or seized motor to restore smooth tray movement and consistent cooking performance.

• Provides slow, consistent rotation of the glass tray during cook cycles
• Helps promote more even heating by turning food under the magnetron
• Typical symptoms: turntable not turning, intermittent or jerky rotation, or humming without movement
• Located beneath the oven cavity, driving the coupler from below

What's included: One synchronous turntable motor Install notes:

• Disconnect power before servicing; microwaves contain high-voltage components that can retain a dangerous charge
• Access is typically from the bottom; remove the bottom cover and mounting screws to reach the motor
• Transfer the two wires one at a time to the new motor and ensure the shaft fully engages the turntable coupler
• Reinstall the cover and test rotation first without the glass tray, then with the tray and support
